IconButton

Component in Material 3 Compose

Icon buttons help people take supplementary actions with a single tap. They’re used when a compact button is required, such as in a toolbar or image list.

Last updated: 2024-10-22 13:47

Installation

dependencies {
   implementation("androidx.compose.material3:material3:1.4.0-alpha02")
}

Overloads

@Deprecated(
    message = "Use overload with `shape`",
    replaceWith =
        ReplaceWith(
            "IconButton(onClick, modifier, enabled, colors, interactionSource, shape, content)"
        ),
    level = DeprecationLevel.HIDDEN
)
@Composable
fun IconButton(
    onClick: () -> Unit,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    colors: IconButtonColors = IconButtonDefaults.iconButtonLocalContentColors(),
    interactionSource: MutableInteractionSource? = null,
    content: @Composable () -> Unit
)

Parameters

name	description
onClick	called when this icon button is clicked
modifier	the [Modifier] to be applied to this icon button
enabled	controls the enabled state of this icon button. When false, this component will not respond to user input, and it will appear visually disabled and disabled to accessibility services.
colors	[IconButtonColors] that will be used to resolve the colors used for this icon button in different states. See [IconButtonDefaults.iconButtonColors].
interactionSource	an optional hoisted [MutableInteractionSource] for observing and emitting [Interaction]s for this icon button. You can use this to change the icon button's appearance or preview the icon button in different states. Note that if null is provided, interactions will still happen internally.
content	the content of this icon button, typically an [Icon]

@OptIn(ExperimentalMaterial3ExpressiveApi::class)
@Composable
fun IconButton(
    onClick: () -> Unit,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    colors: IconButtonColors = IconButtonDefaults.iconButtonLocalContentColors(),
    interactionSource: MutableInteractionSource? = null,
    shape: Shape = IconButtonDefaults.standardShape,
    content: @Composable () -> Unit
)

Parameters

name	description
onClick	called when this icon button is clicked
modifier	the [Modifier] to be applied to this icon button
enabled	controls the enabled state of this icon button. When false, this component will not respond to user input, and it will appear visually disabled and disabled to accessibility services.
colors	[IconButtonColors] that will be used to resolve the colors used for this icon button in different states. See [IconButtonDefaults.iconButtonColors] and [IconButtonDefaults.iconButtonLocalContentColors] .
interactionSource	an optional hoisted [MutableInteractionSource] for observing and emitting [Interaction]s for this icon button. You can use this to change the icon button's appearance or preview the icon button in different states. Note that if null is provided, interactions will still happen internally.
shape	the [Shape] of this icon button.
content	the content of this icon button, typically an [Icon]

Code Examples

IconButtonSample

@Preview
@Composable
fun IconButtonSample() {
    IconButton(onClick = { /* doSomething() */ }) {
        Icon(Icons.Filled.Lock, contentDescription = "Localized description")
    }
}

TintedIconButtonSample

@Preview
@Composable
fun TintedIconButtonSample() {
    IconButton(onClick = { /* doSomething() */ }) {
        Icon(
            rememberVectorPainter(image = Icons.Filled.Lock),
            contentDescription = "Localized description",
            tint = Color.Red
        )
    }
}

XSmallNarrowSquareIconButtonsSample

@OptIn(ExperimentalMaterial3ExpressiveApi::class)
@Preview
@Composable
fun XSmallNarrowSquareIconButtonsSample() {
    // Small narrow round icon button
    FilledIconButton(
        onClick = { /* doSomething() */ },
        modifier =
            Modifier.minimumInteractiveComponentSize()
                .size(
                    IconButtonDefaults.xSmallContainerSize(
                        IconButtonDefaults.IconButtonWidthOption.Narrow
                    )
                ),
        shape = IconButtonDefaults.xSmallSquareShape
    ) {
        Icon(
            Icons.Filled.Lock,
            contentDescription = "Localized description",
            modifier = Modifier.size(IconButtonDefaults.xSmallIconSize)
        )
    }
}

MediumRoundWideIconButtonSample

@OptIn(ExperimentalMaterial3ExpressiveApi::class)
@Preview
@Composable
fun MediumRoundWideIconButtonSample() {
    IconButton(
        onClick = { /* doSomething() */ },
        modifier =
            Modifier.size(
                IconButtonDefaults.mediumContainerSize(
                    IconButtonDefaults.IconButtonWidthOption.Wide
                )
            ),
        shape = IconButtonDefaults.mediumRoundShape
    ) {
        Icon(
            Icons.Filled.Lock,
            contentDescription = "Localized description",
            modifier = Modifier.size(IconButtonDefaults.mediumIconSize)
        )
    }
}
