Compose Component

SwipeToReveal

SwipeToReveal Material composable.

SwipeToReveal social preview

SwipeToRevealSample

@Composable
@Sampled
fun SwipeToRevealSample() {
    SwipeToReveal(
        primaryAction = {
            PrimaryActionButton(
                onClick = { /* This block is called when the primary action is executed. */ },
                icon = { Icon(Icons.Outlined.Delete, contentDescription = "Delete") },
                text = { Text("Delete") },
            )
        },
        onSwipePrimaryAction = {
            /* This block is called when the full swipe gesture is performed. */
        },
        secondaryAction = {
            SecondaryActionButton(
                onClick = { /* This block is called when the secondary action is executed. */ },
                icon = { Icon(Icons.Outlined.MoreVert, contentDescription = "Options") },
            )
        },
        undoPrimaryAction = {
            UndoActionButton(
                onClick = { /* This block is called when the undo primary action is executed. */ },
                text = { Text("Undo Delete") },
            )
        },
    ) {
        Button(
            modifier =
                Modifier.fillMaxWidth().semantics {
                    // Use custom actions to make the primary and secondary actions accessible
                    customActions =
                        listOf(
                            CustomAccessibilityAction("Delete") {
                                /* Add the primary action click handler here */
                                true
                            },
                            CustomAccessibilityAction("Options") {
                                /* Add the secondary click handler here */
                                true
                            },
                        )
                },
            onClick = {},
        ) {
            Text("This Button has two actions", modifier = Modifier.fillMaxSize())
        }
    }
}

SwipeToRevealSingleActionCardSample

@Composable
@Sampled
fun SwipeToRevealSingleActionCardSample() {
    SwipeToReveal(
        primaryAction = {
            PrimaryActionButton(
                onClick = { /* This block is called when the primary action is executed. */ },
                icon = { Icon(Icons.Outlined.Delete, contentDescription = "Delete") },
                text = { Text("Delete") },
                modifier = Modifier.height(SwipeToRevealDefaults.LargeActionButtonHeight),
            )
        },
        onSwipePrimaryAction = {
            /* This block is called when the full swipe gesture is performed. */
        },
        undoPrimaryAction = {
            UndoActionButton(
                onClick = { /* This block is called when the undo primary action is executed. */ },
                text = { Text("Undo Delete") },
            )
        },
    ) {
        Card(
            modifier =
                Modifier.fillMaxWidth().semantics {
                    // Use custom actions to make the primary action accessible
                    customActions =
                        listOf(
                            CustomAccessibilityAction("Delete") {
                                /* Add the primary action click handler here */
                                true
                            }
                        )
                },
            onClick = {},
        ) {
            Text(
                "This Card has one action, and the revealed button is taller",
                modifier = Modifier.fillMaxSize(),
            )
        }
    }
}

SwipeToRevealWithTransformingLazyColumnSample

@Preview
@Composable
@Sampled
fun SwipeToRevealWithTransformingLazyColumnSample() {
    val transformationSpec = rememberTransformationSpec()
    val tlcState = rememberTransformingLazyColumnState()
    val coroutineScope = rememberCoroutineScope()
    val messages = remember {
        mutableStateListOf<String>().apply {
            for (i in 1..100) {
                add("Message #${i}")
            }
        }
    }

    TransformingLazyColumn(
        state = tlcState,
        contentPadding = PaddingValues(horizontal = 16.dp, vertical = 20.dp),
        modifier = Modifier.background(Color.Black),
    ) {
        items(items = messages, key = { it }) { message ->
            val revealState = rememberRevealState()

            // SwipeToReveal should be reset to covered when scrolling occurs.
            LaunchedEffect(tlcState.isScrollInProgress) {
                if (
                    tlcState.isScrollInProgress && revealState.currentValue != RevealValue.Covered
                ) {
                    coroutineScope.launch {
                        revealState.animateTo(targetValue = RevealValue.Covered)
                    }
                }
            }

            SwipeToReveal(
                primaryAction = {
                    PrimaryActionButton(
                        onClick = { messages.remove(message) },
                        icon = { Icon(Icons.Outlined.Delete, contentDescription = "Delete") },
                        text = { Text("Delete") },
                        modifier = Modifier.height(SwipeToRevealDefaults.LargeActionButtonHeight),
                    )
                },
                revealState = revealState,
                onSwipePrimaryAction = { messages.remove(message) },
                transformation = SurfaceTransformation(transformationSpec),
                modifier =
                    Modifier.transformedHeight(this@items, transformationSpec)
                        .animateItem()
                        .minimumVerticalContentPadding(
                            CardDefaults.minimumVerticalListContentPadding
                        ),
            ) {
                TitleCard(
                    onClick = {},
                    title = { Text(message) },
                    subtitle = { Text("Subtitle") },
                    modifier =
                        Modifier.semantics {
                            // Use custom actions to make the primary action accessible
                            customActions =
                                listOf(
                                    CustomAccessibilityAction("Delete") {
                                        messages.remove(message)
                                        true
                                    }
                                )
                        },
                ) {
                    Text("Message body which extends over multiple lines to extend the card")
                }
            }
        }
    }
}

SwipeToRevealWithScalingLazyColumnSample

@Preview
@Composable
@Sampled
fun SwipeToRevealWithScalingLazyColumnSample() {
    val slcState = rememberScalingLazyListState()
    val coroutineScope = rememberCoroutineScope()
    val messages = remember {
        mutableStateListOf<String>().apply {
            for (i in 1..100) {
                add("This Button $i has two actions")
            }
        }
    }

    ScalingLazyColumn(
        state = slcState,
        contentPadding = PaddingValues(horizontal = 16.dp, vertical = 20.dp),
        modifier = Modifier.background(Color.Black),
    ) {
        items(items = messages, key = { it }) { message ->
            val revealState = rememberRevealState()

            // SwipeToReveal should be reset to covered when scrolling occurs.
            LaunchedEffect(slcState.isScrollInProgress) {
                if (
                    slcState.isScrollInProgress && revealState.currentValue != RevealValue.Covered
                ) {
                    coroutineScope.launch {
                        revealState.animateTo(targetValue = RevealValue.Covered)
                    }
                }
            }

            SwipeToReveal(
                revealState = revealState,
                primaryAction = {
                    PrimaryActionButton(
                        onClick = { messages.remove(message) },
                        icon = { Icon(Icons.Outlined.Delete, contentDescription = "Delete") },
                        text = { Text("Delete") },
                    )
                },
                onSwipePrimaryAction = { messages.remove(message) },
                secondaryAction = {
                    SecondaryActionButton(
                        onClick = {
                            /* This block is called when the secondary action is executed. */
                        },
                        icon = { Icon(Icons.Outlined.MoreVert, contentDescription = "Options") },
                    )
                },
            ) {
                Button(
                    modifier =
                        Modifier.fillMaxWidth().semantics {
                            // Use custom actions to make the primary and secondary actions
                            // accessible
                            customActions =
                                listOf(
                                    CustomAccessibilityAction("Delete") {
                                        messages.remove(message)
                                        true
                                    },
                                    CustomAccessibilityAction("Options") {
                                        /* Add the secondary click handler here */
                                        true
                                    },
                                )
                        },
                    onClick = {},
                ) {
                    Text(message, modifier = Modifier.fillMaxSize())
                }
            }
        }
    }
}

SwipeToRevealNoPartialRevealWithScalingLazyColumnSample

@Preview
@Composable
@Sampled
fun SwipeToRevealNoPartialRevealWithScalingLazyColumnSample() {
    val slcState = rememberScalingLazyListState()
    val messages = remember {
        mutableStateListOf<String>().apply {
            for (i in 1..100) {
                add("Message #${i}")
            }
        }
    }

    ScalingLazyColumn(
        state = slcState,
        contentPadding = PaddingValues(horizontal = 16.dp, vertical = 20.dp),
        modifier = Modifier.background(Color.Black),
    ) {
        items(items = messages, key = { it }) { message ->
            SwipeToReveal(
                hasPartiallyRevealedState = false,
                primaryAction = {
                    PrimaryActionButton(
                        onClick = { messages.remove(message) },
                        icon = { Icon(Icons.Outlined.Delete, contentDescription = "Delete") },
                        text = { Text("Delete") },
                    )
                },
                onSwipePrimaryAction = { messages.remove(message) },
            ) {
                Button(
                    modifier =
                        Modifier.fillMaxWidth().semantics {
                            // Use custom actions to make the primary action accessible
                            customActions =
                                listOf(
                                    CustomAccessibilityAction("Delete") {
                                        messages.remove(message)
                                        true
                                    }
                                )
                        },
                    onClick = {},
                ) {
                    Text(message, modifier = Modifier.fillMaxSize())
                }
            }
        }
    }
}
