SegmentedListItem - Composable Component in Material 3 Compose

Lists are continuous, vertical indexes of text or images.

SegmentedListItem

Common

@ExperimentalMaterial3ExpressiveApi
@Composable
fun SegmentedListItem(
    onClick: () -> Unit,
    shapes: ListItemShapes,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    leadingContent: @Composable (() -> Unit)? = null,
    trailingContent: @Composable (() -> Unit)? = null,
    overlineContent: @Composable (() -> Unit)? = null,
    supportingContent: @Composable (() -> Unit)? = null,
    verticalAlignment: Alignment.Vertical = ListItemDefaults.verticalAlignment(),
    onLongClick: (() -> Unit)? = null,
    onLongClickLabel: String? = null,
    colors: ListItemColors = ListItemDefaults.segmentedColors(),
    elevation: ListItemElevation = ListItemDefaults.elevation(),
    contentPadding: PaddingValues = ListItemDefaults.ContentPadding,
    interactionSource: MutableInteractionSource? = null,
    content: @Composable () -> Unit,
)

Parameters


onClick	called when this list item is clicked.
shapes	the `ListItemShapes` that this list item will use to morph between depending on the user's interaction with the list item. The base shape depends on the index of the item within the overall list. See `ListItemDefaults.segmentedShapes`.
modifier	the `Modifier` to be applied to this list item.
enabled	controls the enabled state of this list item. When `false`, this component will not respond to user input, and it will appear visually disabled and disabled to accessibility services.
leadingContent	the leading content of this list item, such as an icon or avatar.
trailingContent	the trailing content of this list item, such as a checkbox, switch, or icon.
overlineContent	the content displayed above the main content of the list item.
supportingContent	the content displayed below the main content of the list item.
verticalAlignment	the vertical alignment of children within the list item, after accounting for `contentPadding`.
onLongClick	called when this list item is long clicked (long-pressed).
onLongClickLabel	semantic / accessibility label for the `onLongClick` action.
colors	the `ListItemColors` that will be used to resolve the colors used for this list item in different states. See `ListItemDefaults.segmentedColors`.
elevation	the `ListItemElevation` used to resolve the elevation for this list item in different states. See `ListItemDefaults.elevation`.
contentPadding	the padding to be applied to the content of this list item.
interactionSource	an optional hoisted `MutableInteractionSource` for observing and emitting `Interaction`s for this list item. You can use this to change the list item's appearance or preview the list item in different states. Note that if `null` is provided, interactions will still happen internally.
content	the main content of this list item. Also known as the headline or label.

SegmentedListItem

Common

@ExperimentalMaterial3ExpressiveApi
@Composable
fun SegmentedListItem(
    selected: Boolean,
    onClick: () -> Unit,
    shapes: ListItemShapes,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    leadingContent: @Composable (() -> Unit)? = null,
    trailingContent: @Composable (() -> Unit)? = null,
    overlineContent: @Composable (() -> Unit)? = null,
    supportingContent: @Composable (() -> Unit)? = null,
    verticalAlignment: Alignment.Vertical = ListItemDefaults.verticalAlignment(),
    onLongClick: (() -> Unit)? = null,
    onLongClickLabel: String? = null,
    colors: ListItemColors = ListItemDefaults.segmentedColors(),
    elevation: ListItemElevation = ListItemDefaults.elevation(),
    contentPadding: PaddingValues = ListItemDefaults.ContentPadding,
    interactionSource: MutableInteractionSource? = null,
    content: @Composable () -> Unit,
)

Parameters


selected	whether or not this list item is selected.
onClick	called when this list item is clicked.
shapes	the `ListItemShapes` that this list item will use to morph between depending on the user's interaction with the list item. The base shape depends on the index of the item within the overall list. See `ListItemDefaults.segmentedShapes`.
modifier	the `Modifier` to be applied to this list item.
enabled	controls the enabled state of this list item. When `false`, this component will not respond to user input, and it will appear visually disabled and disabled to accessibility services.
leadingContent	the leading content of this list item, such as an icon or avatar.
trailingContent	the trailing content of this list item, such as a checkbox, switch, or icon.
overlineContent	the content displayed above the main content of the list item.
supportingContent	the content displayed below the main content of the list item.
verticalAlignment	the vertical alignment of children within the list item, after accounting for `contentPadding`.
onLongClick	called when this list item is long clicked (long-pressed).
onLongClickLabel	semantic / accessibility label for the `onLongClick` action.
colors	the `ListItemColors` that will be used to resolve the colors used for this list item in different states. See `ListItemDefaults.segmentedColors`.
elevation	the `ListItemElevation` used to resolve the elevation for this list item in different states. See `ListItemDefaults.elevation`.
contentPadding	the padding to be applied to the content of this list item.
interactionSource	an optional hoisted `MutableInteractionSource` for observing and emitting `Interaction`s for this list item. You can use this to change the list item's appearance or preview the list item in different states. Note that if `null` is provided, interactions will still happen internally.
content	the main content of this list item. Also known as the headline or label.

SegmentedListItem

Common

@ExperimentalMaterial3ExpressiveApi
@Composable
fun SegmentedListItem(
    checked: Boolean,
    onCheckedChange: (Boolean) -> Unit,
    shapes: ListItemShapes,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    leadingContent: @Composable (() -> Unit)? = null,
    trailingContent: @Composable (() -> Unit)? = null,
    overlineContent: @Composable (() -> Unit)? = null,
    supportingContent: @Composable (() -> Unit)? = null,
    verticalAlignment: Alignment.Vertical = ListItemDefaults.verticalAlignment(),
    onLongClick: (() -> Unit)? = null,
    onLongClickLabel: String? = null,
    colors: ListItemColors = ListItemDefaults.segmentedColors(),
    elevation: ListItemElevation = ListItemDefaults.elevation(),
    contentPadding: PaddingValues = ListItemDefaults.ContentPadding,
    interactionSource: MutableInteractionSource? = null,
    content: @Composable () -> Unit,
)

Parameters


checked	whether this list item is toggled on or off.
onCheckedChange	called when this toggleable list item is clicked.
shapes	the `ListItemShapes` that this list item will use to morph between depending on the user's interaction with the list item. The base shape depends on the index of the item within the overall list. See `ListItemDefaults.segmentedShapes`.
modifier	the `Modifier` to be applied to this list item.
enabled	controls the enabled state of this list item. When `false`, this component will not respond to user input, and it will appear visually disabled and disabled to accessibility services.
leadingContent	the leading content of this list item, such as an icon or avatar.
trailingContent	the trailing content of this list item, such as a checkbox, switch, or icon.
overlineContent	the content displayed above the main content of the list item.
supportingContent	the content displayed below the main content of the list item.
verticalAlignment	the vertical alignment of children within the list item, after accounting for `contentPadding`.
onLongClick	called when this list item is long clicked (long-pressed).
onLongClickLabel	semantic / accessibility label for the `onLongClick` action.
colors	the `ListItemColors` that will be used to resolve the colors used for this list item in different states. See `ListItemDefaults.segmentedColors`.
elevation	the `ListItemElevation` used to resolve the elevation for this list item in different states. See `ListItemDefaults.elevation`.
contentPadding	the padding to be applied to the content of this list item.
interactionSource	an optional hoisted `MutableInteractionSource` for observing and emitting `Interaction`s for this list item. You can use this to change the list item's appearance or preview the list item in different states. Note that if `null` is provided, interactions will still happen internally.
content	the main content of this list item. Also known as the headline or label.
